AUXIGAINE protection enclosure mounting bracket for symmetrical DIN rail mounting

The supply and connection unit provides the electrical connection of AUXIGAINE using a 10–25 mm² insulated cable (cable not included). The protective sheath fixing is intended for securing up to 3 AUXIGAINE units or 6 conductors and must be installed every 500 mm. The protective sheath fixing support enables the fixing to be mounted on a symmetrical DIN rail, flat surface or bracket. The end fixing clips onto a symmetrical or asymmetrical rail either parallel or perpendicular and can also be mounted on a sheet-metal surface. It is intended to secure AUXIGAINE and prevent movement. The seal provides AUXIGAINE IP20 touch protection between connection points. The end stop provides insulation and securely holds the conductor when it has to be cut to length.
